Power
Amplifier |
|
|
|
FEATURE:
- Amplifier protection
Short Circuit, open circuit, and ultrasonic, and therefore
protection, open muting; stable into reactive or mismatched
loads
- Load protection
On/off muting, clip limiting, DC-fault load grounding
relay with internal fuses
- Output Circuit
type
Complementry linear outputs ; 2 step high-efficiency
circuitry
|
|
Model
|
PRO 250A
|
SPECIFICATIONS
|
Output
power (per channel) |
|
8 Ω , 1 KHz , 0.04%
THD |
250 W |
4
Ω , 1 KHz , 0.04% THD |
350
W |
Output power (Bridged
mono) |
|
8Ω
, 1 KHz , 0.04% THD |
350
W ~ 450 W |
Distortion |
|
Total
Harmonic Distortion (THD) |
0.5% |
Frequency Response |
20 Hz ~ 20 KHz ,±0.1
dB |
|
8
Hz ~ 100 KHz, ±3 dB |
Damping Factor |
> 200 |
Dynamic
Headroom |
3
dB @ 4Ω |
Noise |
100 dB below rated
output
(20 Hz ~20 KHz) |
Input
Impedance |
1.0
KΩ unbalanced |
|
2.0 KΩ balanced |
Controls
|
|
|
Front |
AC
switch , CH1 and CH2 Gain (continuous) |
|
Rear |
Stereo / Bridge switch |
Indicators |
|
|
Power |
Red LED |
|
Signal |
Green
LED |
|
Clip |
Green LED |
|
Protect |
Red
LED |
Connectors (each channel) |
|
|
Input |
XLR
connector and 1/4" RTS phone |
|
Speakers |
5 way binding posts |
Cooling
|
Two
fans fronts to rear airflow |
Power Requirements |
~220 VAC 50 Hz |
|
|
|
|
|
|
