 Professional
Power Mixer |
|
|
|
| |
|
FEATURE:
- 8 Mono Input Channels
with gold plated XLRs and balanced Line inputs
- Extremely high
headroom - offering more dynamic range
- Balanced inputs
for highest signal integrity
- Ultra - musical
2 - band EQ on all mono channels
- Peak LEDs all Mono
Channels
- 2 AUX Send per
channel for external effects and monitoring
- Digital of the
effect system inside
- Separate Master
Mix, Control Room and Headphone Outputs
- 2 - Track Inputs
assignable to Master Mix Output
- Highly accurate
10 segments Bargraph Meters
|
| |
|
Model |
MT 80
|
|
SPECIFICATIONS
|
| Mic
Input B |
electronically
balanced, discrete input configuration
|
|
Bandwidth |
10 Hz ~ 60 KHz ± 3dB |
| Distortion
|
0.01
% at +4 dBu, 1 KHz |
|
Mic E.I.N (22 Hz ~
22 KHz) |
-129.5 dBu, 150 Ω |
| |
-117.3
dBqp, 150 Ω |
| |
-132.0 dBu, input
shorted |
| |
-122.0
dBqp, input shorted |
|
TRIMrange |
+10 dB ~ 60 dB |
| Line
Input |
electronically
balanced |
|
Line Level Range |
10 dBu ~ 4 dBu |
|
|
|
|
Equalization |
|
Hi Shelving |
12 KHz ± 15dB |
| Mid
Range |
2.5
KHz ± 15dB |
|
Lo Shelving |
80 Hz ± 15dB |
| Max
Output |
+
22 dBu balanced |
|
Aux Send Max out |
+ 22 dBu unbalanced |
| Control
Room out |
+
22 dBu unbalanced |
|
Signal To Noise Ratio |
+ 112 dB all channels
at Unity Gain |
| Line
Channel |
8
CH |
|
Main Buses |
1 Stereo |
| Group
Buses |
1
Stereo |
|
Effector |
18 Hz ~ 18 KHz |
| Power
Output |
4
Ω 400 W *2 |
|
| |
|
| |
|
|
