 Professional
Power Mixer |
|
|
|
| |
|
FEATURE:
- +48 V Phantom Power
- 2 Group main channel
output
- 1 Group Aux line
output, return and send
- 3 Band EQ adjustment
for each input channel
- Built in Echo effector
- 2 x 7 Band Master
EQ
- 2 Groups 3-color
10 Band level Indicator
- Built-in audio
power amplifier
|
| |
|
Model |
MB 60
|
|
SPECIFICATIONS
|
|
Channel Mic/Line |
6 Channel |
|
Channel EQ |
3 Band |
|
Main Buses |
1 Stereo |
|
Group Buses |
1 Stereo |
|
Frequency Resposne |
18 Hz ~ 18 KHz |
|
Power Output |
4 Ω 200 W x 2 |
|
|
|
Advance |
|
Input Channel Sensitivity |
|
| |
MIC |
-60 dB |
|
|
STEREO CH. INPUT |
-40 dB |
| |
EFX
SEND |
-20 dB |
|
|
EFF, RETURN |
- 20 dB |
|
OUTPUTS |
4 V MAX |
|
OUTPUTS |
-80 dB |
|
PARMETRIC EQ |
|
|
|
HI |
+15 dB / 10 KHz |
| |
MID |
± 15 dB / 250
Hz ~ 6 KHz |
|
|
LOW |
± 15 dB / 60 Hz |
|
T.H.D |
0.1 % below (1
KHz Full Power) |
|
Power Requirement |
AC 220 V / 50 Hz
or 120 V / 60 Hz |
|
Power Consumption |
300 W |
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
| |
|
| |
|
|
