MINI HIFI COMBO |
|
|
|
| |
|
FEATURE:
- USB Input for music player MP3/WMA/AAC format
- Support PC-DAC features a computer with a USB data cable to connect, via the local keypad or remote control can directly control the computer's multimedia player, and computer-fidelity music playback
- Tube class A amplifier
- Built-in FM digital tuner radio module
- LED digital tube display system
- Full function remote control
- Front Stereo headphone jack
- line input for other audio source
|
| |
|
Model |
MM 1 |
|
SPECIFICATIONS
|
|
Rated output power |
2W +2 W (RMS: 8Ω) |
|
Tube Used |
6P1 × 2,
6 N1 × 2 |
|
Frequency Response |
20Hz ~ 22kHz (± 1dB) |
|
THD |
3% (1kHz) |
|
Input Sensitivity |
600mV |
|
AUX IN (RCA) |
500mV (RMS) |
|
Input impedance |
100kΩ |
|
USB storage device |
USB A type connector,
full-speed (12 Mbps) |
| USB Audio |
USB B-type connector,
full-speed |
|
Sampling frequency |
32kHz, 44.1kHz, 48kHz |
| Headphone jack |
32Ω ~ 300Ω stereo headphones |
|
Power Input |
AC 100V ~ 240V |
Max power cons.
|
60W
|
|
SPEAKER (SP10)
|
|
Rated Power |
40W |
|
Impedance |
6Ω |
|
Sensitivity |
88dB |
|
Frequency Response |
100Hz ~ 24kHz |
|
|
|
|
FM TUNER
|
|
Tuner |
FM stereo |
|
Frequency range |
87.5MHz ~ 108MHz
(in steps of 0.1MHz) |
|
Noise sensitivity |
better than 5uV |
|
| |
|
| |
|
|
