Disc Player |
|
|
[click on photo to enlarge]
|
|
HI-FI
CD player
|
| |
|
FEATURE:
- Aluminum die-cast,
VFD and LED Dual display, elegant look
- Using SONY KSS213Q
Laser pick-up system and PHILIPS CD18 servo circuit
- Utilizes American
companies CRYSTAL-chip CS 4398 digital filter, D/A Converter
- Audio output circuit
using 12 AU7 tube for buffer output
- Equipped with a
high-performance optical and coaxial digital signal
output
- Headset with a
digital volume control
- Low-pass filter
circuit using a dedicated high-quality audio op amp
- Specifically use
of this machine developed by low magnetic leakage high-efficiency
EI transformer
|
| |
|
Model |
MT-CD 40
|
|
SPECIFICATIONS
|
|
Output Level |
2 V± 3dB |
| Frequency Response |
20 Hz ~ 20 KHz
± 0.5 dB |
|
Distortion and noise |
< -60 dB |
| S/N Ratio |
85 dB |
|
Dynamic Range |
82 dB |
| Channel separation |
70 dB (1 KHz) |
|
Digital Output Characteristic |
According to the IEC
958 standard |
| Power Requirement |
~ 220 V
± 5% 50 Hz |
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
| |
| |
|
| |
|
|
