 Wireless
Micorphone |
|
|
|
| |
|
FEATURE:
|
| |
|
Model |
PWM 811B
|
|
SPECIFICATIONS
|
|
Receiver Mode |
Crystal Frequency
Lock |
| Freq. Range |
170 ~ 260 MHz |
|
Freq. Stability |
15 PPM |
| Sensitivity |
3 µV 30 dB S/N |
|
S/N Ratio |
60 dB |
| Audio output |
0 ~ 0.5V / 4.7
K |
Power
|
AC 120 ~ 240 V
|
|
System
|
|
Freq. Range |
170 ~ 260 MHz |
| Freq. Stability |
± 0.005% |
|
Modulate Mode |
FM |
| Freq. Response |
50 ~ 16 KHz |
|
S/N Ratio |
> 60 dB |
| Maximum Sound
Pressure |
≥ 120 dB |
|
Distortion Factor |
< 1% |
| Effective field |
30 m |
Operation Temperature
|
10°C ~ + 50°C
|
|
Transmitter
|
|
Freq. Range |
170 ~ 260 MHz |
| Freq. Stability |
15 PPM |
|
Modulate Mode |
> 30 KHz |
| Emission Power |
30mV Max |
|
Harmonic Suppression |
40 dB |
| Battery
|
9V Alkaline Batt. |
|
|
1.5 V AA batt. |
| Antenna |
Built in |
|
Battery Current |
25 ~ 30 mA |
|
| |
|
| |
|
|
