 HI-END Karaoke
Amplifier |
|
|
Hyper
Quality Stereo Digital Processing Karaoke Amplifier
|
| |
|
FEATURE:
-
Hi-fidelity digital
Echo/Reverb processing.
-
2 channels power
output: 200W + 200W/ at 8 ohm
-
Wireless remote
controller (music volume, microphone volume and
key)
-
11 steps digital
stereo key control.
-
Automatic and Manual
input source select.
-
Font panel reserves
3 microphones input jacks, and Rear panel reserves
2
microphones input jacks for usage.
-
Individual microphones
Volume/Bass/Mid-range/Treble adjustment.
-
Echo repeat-length
and Delay-time controller.
-
Individual Music
Volume/Bass/Mir-range/Treble and Balance adjustment.
-
Auto gain control
switching to balance the music inputs level automatically.
-
Unique microphone
signal jack used for external DSP sound effector.
-
Remote control
jack for external Song ordering system to track
selecting.
-
Auto Video input/output
switching.
-
Dual AC voltage
(AC115V/230V) selector.
-
Advanced low-noise
tunnel type headsink blowing system.
-
Overload and short
circuit protecting.
-
Reserve Pre-out/Sub-out/Rec-out/Music-out
for external devices.
|
| |
|
Model |
DA 2200
|
|
SPECIFICATIONS
|
|
Maximum power
output:
|
200W
+ 200W at 8 ohm. |
|
Total Harmonic
Distortion:
|
0.03% |
| |
|
Input Jacks (Sensitivity/Impedance)
|
|
MIC
|
6mV/3.3K
ohm. |
|
DVD,TAPE,AUX
|
300mV/ 47K ohm. |
BGM
|
300mV/
47K ohm.
|
Output Jacks (Level/Impedance)
|
|
REC OUT
|
300mV/2.2K
ohm. |
|
MUSIC OUT
|
2.5V/2.2K ohm.
|
|
PRE OUT
|
2.5V/2.2K
ohm. |
|
SUB OUT
|
2.0V/2.2K ohm. |
|
|
|
|
Frequency Response |
|
MIC
|
20Hz
- 20KHz. |
|
MUSIC |
20Hz - 20KHz |
|
Key Control Range
|
11
steps +/-5tones |
|
Video Input Jack
Sensitivity/Impedance
|
1Vp-p/75 ohm. |
|
Video Output Jack
Level/Impedance
|
1Vp-p/75
ohm. |
|
Power Consumption |
650W |
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
| |
|
| |
|
|
