 Wireless
Microphone |
|
|
|
| |
|
FEATURE:
|
| |
|
Model |
MVX 292
|
|
SPECIFICATIONS
|
|
Carrier Frequency
Range |
200 ~ 270 MHz, VHF
High Band |
| Frequency Stability
|
±0.005% with Quatz
Control |
|
Modulation |
FM |
| Maximum Deviation
Range |
±15Khz |
|
Frequency Response |
40 Hz ~ 20 KHz |
| Signal To Noise
Ratio |
> 100dB |
|
Audio Dynamic Range |
> 100dB |
| T.H.D |
< 0.5% |
|
Service Area |
30 meters (in best
condition) |
| Temperature Range |
-10°C ~ 50 °C |
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
| |
|
| |
|
|
