 Karaoke
Amplifier |
|
|
|
| |
|
FEATURE:
- 2 Stereo Input
- Auto Input Selector
- 2 Video Input,
2 Output (RCA)
- BGM Input
- PRE OUT
- Unwsitched AC Outlets
- Switched AC Outlets
|
| |
|
Model |
KA 650 II
|
|
SPECIFICATIONS
|
|
Max output power: |
150W + 150W
|
| Total
Harmonic Distortion |
0.05%(1KHz,
60W, 8Ω) |
|
Audio Jacks (Sensitivity,Impedance) |
| |
Mic |
4.5
mV / 3.5Ω |
| |
CD,AUX |
300 mV / 20 KΩ |
| |
BGM |
300
mV / 22 KΩ |
|
Audio Output Jacks(Output
Level, Impedance) |
| |
Pre
Output |
2V/
1KΩ |
| |
Music Effector |
300 mV / 1KΩ |
| |
Recording
Output |
300
mV / 1KΩ |
|
Frequency Response |
|
| |
Mic |
40~15
Khz, +8/-3dB |
| |
Music |
20~20KHz, +8/-3dB |
| Tone
Characteristic |
|
| |
Music (Bass @
100Hz, Treble @ 10KHz) |
±8dB |
| |
Mic
(Bass @ 100Hz, Treble @ 10KHz) |
±8dB |
|
Speaker Impedance |
4~16Ω(A/B), 8~32(A&B) |
| Key
Control Range |
11
Steps, +2-1/2 |
|
Video Input/Output
Jack |
1 Vp-p/75Ω
|
| Power
Supply Voltage |
AC
240V 50/60 Hz |
|
Power Consumption |
600 W |
|
| |
|
| |
|
|
