 Karaoke
Amplifier |
|
|
|
| |
|
FEATURE:
-
Classical
plastic front panel
-
High
efficient square transformer, imported large electrolytic
capacitors margin lr energy
-
4 pairs
of large power TOSHIBA transistor output
-
3-route
microphone input, volume, tone and sound effect in push-in
style adjustment, May use five microphone
-
3-route
audio input, 3-route video input/output
-
Audio/Video
input auto detect function, input sensitivity adjustable
-
Built-in
24BIT digital conditioned circuit
-
Infrared
wireless remote control. Volume reset to zero on startup
-
Full
functional protective circuit
-
Rated
output power 120W+120W(8ohms)
|
| |
|
Model |
KA 1800 J9
|
|
SPECIFICATIONS
|
| Power Output
For
E version |
200
W + 200 W(1 KHz, 6 Ω) |
|
Total Harmonic Distortion
|
0.05%(1 KHz, 60W,
8Ω) |
|
|
|
Sensitivity
/ Impedance |
|
MIC Input Jacks |
4.5mV / 3.5 KΩ |
| DVD,
AUX Input Jacks |
300mV
/ 20 KΩ |
|
BGM Input Jacks |
300mV / 10 KΩ |
|
PRE-Output
Level/Impedance |
2V /1 KΩ |
|
MIC
Freq. Response |
40 Hz ~ 15 KHz ,+8/-3
dB |
| MUSIC Freq. Response |
20
Hz ~ 20 KHz, +8/-3 dB |
|
Video Input Jack |
1 Vp-p / 75 Ω |
|
Video Output Jack
|
1
Vp-p / 75Ω |
|
|
|
|
Characteristics |
|
MUSIC |
BASS |
+8/-10
dB(100 KHz) |
|
|
TREBLE |
+8/-10 dB(100 KHz) |
|
MICROPHONE |
BASS |
±
10 dB (100 Hz) |
|
|
TREBLE |
± 10 dB (10 KHz) |
|
Key Control Range |
11
Steps, ± 2/ ½ tones |
|
Power Supply |
|
Supply Voltage |
AC
220 ~ 240 V
50 Hz / 60 Hz |
|
Power Consumption |
600 W |
|
UnSwitched (300 W
max) |
2 |
|
| |
|
| |
|
|
