 AMPLIFIER |
|
|
|
| |
|
FEATURE:
- Infrared Remote
Control
- 9 Steps Digital
Key Control
- Overload and Short
Protecting Circuit
- Dual Voltage(110V/220V)
for select
- Innvative Digital
Echo Effect & Echo Tone Adjustment
- PRE OUT
- EQ IN/OUT
- 3 Video Input 1
Output (RCA)
- 3 Stereo Input
|
| |
|
Model |
PURESOUND 22
|
|
SPECIFICATIONS
|
|
Audio output max |
100 W per channel |
| Mic
input sensitivity |
10mV |
|
External devices sensitivity |
200 mV |
| Signal
/ Noise Ratio |
80
dB(with IHF A Filter) |
|
T.H.D.(1 KHz AUX 150mV
INPUT) |
0.1% |
| Frequency
Response |
25
Hz ~ 20 KHz |
|
Mic. Tone adjustment |
80 Hz ± 15 dB |
| |
3.5
KHz ± 8 dB |
| |
12 KHz ± 15 dB |
| Echo
Tone adjustment |
80
Hz ± 15 dB |
| |
12 KHz ± 15 dB |
| Power
Source |
AC
110 V / 60 Hz |
| |
AC 230 V / 50 Hz |
| Electricity
Consumption |
450
W |
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
| |
|
| |
|
|
