Ceiling Speaker |
|
|
|
| |
|
FEATURE:
- Existing Home Multi-Room
Audio Retrofit
- Light Commercial
- Lamp and Pendant
Installations
- Home Theatre Wireless
Rear Channel
- Outdoor
- Vacation Homes/Resorts
- Apartments/Condos/Rentals
- Addition to wired
homes
- Soffit Can Lights
- Baths/Hallways
|
| |
|
Model |
LS 5.2.2
|
|
SPECIFICATIONS
|
| Transmitter
Sources |
2 |
|
Discrete Transmitter
Zones |
2 |
| Audio
Transmission Frequency |
2.4
GHz proprietary |
|
RF Remote Transmission
Frequency |
908 MHz |
| Audio
Transmitter range (omni-directional) |
50'
to 100' (depend on environment) |
|
RF Remote range (omni-directional) |
50' to 100' (depend
on environment) |
| AC
power |
100
VAC to 240 VAC |
|
Dimensions |
5.9", 151mm
7" , 177mm
2.4" 60, mm |
|
|
|
|
LS 5 (UNIT)
|
|
Woofer |
3" Micro Cellulose |
| Light
Brightness |
10
W LED |
|
Wireless Reception |
2.4 GHz Proprietary
signal |
| Frequency
Response |
[±3dB]
90 Hz ~ 20 KHz |
|
Amplifier Power |
20 W |
| MAX
SPL |
93
dB |
|
Light Speaker® depth |
5.7", 145.8mm (w/out
Edison screw) |
| Light
Speaker® diameter |
5.1",130mm
(w/out Flange) |
|
Light Speaker® diameter |
7.6" , 192 mm (with
Flange) |
| Depth
without socket |
5.5"
, 140mm no lens |
|
Depth with socket
|
6.8" , 173.6 mm no
lens |
| Depth
without Socket with lens |
6.2"
, 156.7mm |
|
Depth with Socket
with lens |
7.4", 189mm
|
| Depth
of Light Bracket |
8.0"
, 202mm with Flange |
|
Depth of Light Bracket |
8.1" , 207mm with
Flange |
| Weight |
2.11
lbs, 0.96 Kgs |
|
| |
|
| |
|
|
