5.1 CHANNEL A/V RECEIVER













FEATURE:

  • DOLBY DIGITAL, PRO-LOGIC II, and DTS decoding
  • Independent amplifying circuit with 5 sound channels
  • High power ring transformer
  • Perfect loudspeaker protection circuit
  • Infrared fully remote control
  • 7 DSP effects
  • FM/AM

 Model

AV 508

SPECIFICATIONS
Main Channel Power
Output (8Ω)		 80 W x 2 (Rated Value RMS )
300 W x 2 (PMPO)
Center Channel Power
Output( 8Ω)		 80 W (Rated Value RMS)
300 W (PMPO)
Surround Channel Power
Output (8Ω) 		80 W x 2 (Rated Value RMS)
300 W x 2 (PMPO)
Rated THD 1%
Frequency Response 20 Hz ~ 20 KHz (± 3dB)
Signal-Noise Ratio 85 dB (A Weighted)
Input Sensitivity 300 mV
Pwoer Supply 230 V 50/60 Hz
Power Consumption < 500 W
Frequency Range AM 522 KHz ~ 1611 KHz
(Step length:9 KHz)
Frequency Range FM 530KHz ~ 1610 KHz
(Step length: 10 KHz)
Sensitivity AM 87 MHz ~ 108 MHz
Sensitivity FM <6mV / m
Signal To Noise Ratio AM >34 dB(A-weighing)
Signal To Noise Ratio FM > 45 dB
