5.1 Speaker System |
|
|
|
| |
|
FEATURE:
|
| |
|
Model |
AM 903
|
|
SPECIFICATIONS
|
| Peak Music Power
Output (PMPO) |
6W + 6W |
|
Rated Output (THD=2%,
1KHz) |
≥ 2W + 2W |
| Total Harmonic
Distortion |
≤ 2% (200 Hz
~ 12.5 KHz ± 3dB) |
|
Signal-to-Noise Ratio
(Line Output) |
≥ 72 dB (A Weighted) |
|
|
|
|
Subwoofer Channel |
|
Peak Music Power Output
(PMPO) |
25 W |
| Rated Output (THD=2%,
60 Hz) |
≥ 18 W |
|
Total Harmonic Distortion |
≤ 2% |
| Frequency Response
(Line Input) |
35 Hz ~ 200 Hz
(± 6.5 dB) |
|
Signal-to-noise Ratio
(Line Input) |
≥ 78 dB (A-Weighted) |
| Impedance
|
Line Input (500
mV /47 KΩ |
|
Power Consumption |
90 W |
| Rated Impedance
|
Each channel 4
Ω |
|
Power |
220 V ~ 240 V 50/60
Hz |
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
| |
|
| |
|
|
