 Karaoke
Amplifier |
|
|
 |
| |
|
FEATURE:
- 2 Stereo Audio Input
- 2 Video (RCA) Input 1 Output
- 1 MIC OUT , HIGH & LOW
- Music Mode, DISCO, HIFI
- Line and REC Output
|
| |
|
Model |
VOICE
920 MK II |
SPECIFICATIONS |
|
Audio Output Max. |
300W+300W |
|
Mic Input Sensitivity
|
15 mV |
|
External devices
sensitivity |
250 mV |
|
Signal/ Noise ratio |
80 dB ( with IHF A Filter) |
|
T.H.D (1 KHz AUX 150 mV
Input) |
0.1% |
|
Frequency Response |
25Hz~20 KHz |
|
Mic. Tone adjustment
|
80 Hz ± 15dB
3.5 KHz ± 5dB
12 KHz ± 15dB |
|
Echo tone adjustment |
80 Hz ± 15dB
12 KHz ±15dB |
|
Power Source |
AC 230 V /50 Hz |
|
Power Consumption |
650 W |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
| |
|
|
