 Amplifier Set |
|
|
2 Channel, 4 Channel, 5 Channel Driver |
| |
|
FEATURE
- Four Class "AB"
High-Current Dual Discrete Drive Stages.
- Class "AB" Technology
MOSFET PWM Power Supply.
- Bridgeable & TRI-Mode
Operation.
- Continuously Variable 12dB
/ Octave High Pass & 12dB/Octave Low Pass Crossover.
- Subwoofer Variable
Crossover for Deep Bass Control.
- Enhanced Variable Bass
Boost 0dB/ +6dB/ +12 dB @50 Hz
- Gold Plated RCA & Power,
Speaker Terminal.
- SOft Start & Muting.
- Overload, Thermal, Short
Circuit Protection
- Power & Protection
Indicator
|
| |
|
Model |
XTR-4150 |
|
SPECIFICATIONS
|
|
Average Power Output/CH into 4Ω |
10 Hz~40 KHz, 0.5% THD |
50 W x 4 CH |
1 KHz,
10% THD |
175 W x 4 CH |
|
Low Pass Filter (Variable) |
40 Hz ~ 150 Hz |
|
High Pass Filter (Variable) |
80Hz ~1.2KHz |
|
Output of Bridged (BTL)
Operation Into 4Ω @ 1 KHz,1% THD |
700 Watts |
|
Frequency Response (-1 dB) |
5 Hz~50 KHz |
|
Signal To Noise Ratio ("A" WTD) |
> 100 dB |
|
Input Sensitivity |
200mV ~ 2V |
|
Input Impedance |
10K Ω |
|
Operation Voltage (Negative
Ground) |
DC 12V |
|
Speaker Impedance @ Stereo
Driven |
4 Ω |
|
Fuse Rating |
40 A |
|
| |
|
Model |
XTR-6600 |
|
SPECIFICATIONS
|
|
Average Power Output/CH into 4Ω |
10 Hz~40 KHz, 0.5% THD |
150 W x 2 CH |
1 KHz,
10% THD |
400 W x 2 CH |
|
Low Pass Filter (Variable) |
40 Hz ~ 150 Hz |
|
High Pass Filter (Variable) |
80 Hz ~ 1.2 KHz |
|
Output of Bridged (BTL)
Operation Into 4Ω @ 1 KHz,1% THD |
800 Watts |
|
Frequency Response (-1 dB) |
5 Hz~50 KHz |
|
Signal To Noise Ratio ("A" WTD) |
> 100 dB |
|
Input Sensitivity |
200mV ~ 2V |
|
Input Impedance |
10K Ω |
|
Operation Voltage (Negative
Ground) |
DC 12V |
|
Speaker Impedance @ Stereo
Driven |
4 Ω |
|
Fuse Rating |
30 A x 2 |
|
| |
