 PRE-Amplifier |
|
4 Band Graphic Equalizer
|
| |
|
FEATURE:
|
| |
|
Model |
PSM-6 |
|
SPECIFICATIONS
|
|
Bass Equalizer Frequency |
40 Hz |
|
Mid Bass Equalizer Frequency |
200 Hz |
|
Mid Equalizer Frequency |
2 KHz |
|
Hi Equalizer Frequency |
20 KHz |
|
Parametric Equalizer Range |
± 18dB |
|
S/N Ratio |
80 dB Ref 1 V Input |
|
Frequency Response |
10 Hz ~ 50 Hz , ± 1dB |
|
Maximum Output Voltage |
7 V Rms |
|
T.H.D |
0.05% |
|
Input Impedance |
20 KΩ |
|
Stereo Separation |
80 dB / 1 KHz |
|
Subwoofer Frquency Range |
30 Hz ~ 90 Hz |
|
Operation Voltage |
11 ~ 15 VDC negative Ground |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
| |
|
|
