 Amplifier Set |
|
|
|
| |
|
FEATURE:
|
| |
|
Model |
RA-
PLATINUM
2.5 |
RA-PLATINUM
2.9 |
|
SPECIFICATIONS
|
|
Channels |
2 / 1
Channel |
2 / 1
Channel |
|
RMS Power
( 4 Ω) |
2 x
50 Watts |
2 x
90 Watts |
|
RMS Power (2 Ω) |
2 x 75 Watts |
2 x 110 Watts |
|
RMS Power Bridged (4Ω) |
1 x 150 Watts |
1 x 220 Watts |
|
T.H.D |
< 0.05% |
< 0.05% |
|
Frequency Response |
20 Hz ~ 20 KHz |
20 Hz ~ 20 KHz |
|
Signal To Noise Ratio |
> 85 dB |
> 85 dB |
|
Separation @ 1KHz |
> 50 dB |
> 50 dB |
|
Input Sensitivity |
200 mV ~ 4 V |
200 mV ~ 4 V |
|
Bass EQ |
± 18dB |
± 18dB |
|
Crossover |
HP 50 ~ 250 Hz
LP 50 ~ 250 Hz |
HP 50 ~ 250 Hz
LP 50 ~ 250 Hz |
|
Input Impedance |
> 20 K Ω |
> 20 K Ω |
|
Idle Current |
< 1.0 A |
< 1.0 A |
|
Damping Factor |
> 150 |
> 150 |
|
Fuse Rating |
2x 20 Amp |
2 x 30 Amp |
|
| |
|
| |
|
|
