AMPLIFIER |
|
4 Channel Amplifier
|
|
FEATURE
- Proprietary Orion
Industrial Design with illuminated badging
- Directed's patent
pending ESP® (models HP-2800, HP-4800)
- Massive
loosely-regulated MOSFET power supply
- All new pure MOSFET
output stage design
- Intelli-Bass
Equalization Circuit and Remote Gain Option (remote bass
optional on models HP-2800, HP-4800)
- Heavy Gauge
Direct-wire High Current Power and Speaker Terminals
- 12dB/octave High- and
Low-pass Filter
|
|
Model |
HP 4600 |
HP 4800 |
SPECIFICATIONS |
Channels |
4 CH |
4 CH |
Power Rating at 4Ω |
4 x 50 W |
4 x 65 W |
Power Rating at 2Ω |
4 x 75W |
4 x 100 W |
Power Bridge at 4Ω |
2 x 150w |
1 x 200 W |
Impedance |
4 Ω |
4 Ω |
THD + N |
1% |
1% |
Signal to Noise Ratio
(@1 W into 4Ω ) |
-80dBA |
-80dBA |
Crossover |
50Hz~500KHz |
50Hz~500KHz |
Dimension
(WxDxH) mm |
250 x 260 x 61 |
320 x 260 x 61 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
