 AMPLIFIER |
|
|
2 Channels Amplifier
|
| |
|
FEATURE
- Intelli-BassTM
variable bass equalization
- Intelli-Qtm bass
optimization circuit and remote gain option
- 2-Way variable
crossover and high-level input
- Separate adjustable,
variable 2-way active crossovers w/proprietary Copy
Master control circuit for RCA outputs
- Copy/Master feature
supports high-pass, low-pass, or bandpass
configuration
and gain matching for multiple amp systems
- Heavy gauge
direct-wire high current satin finish power and speaker
terminals
- Mono/stereo switchable
|
| |
|
Model |
3002 |
4002 |
6002 |
8002 |
SPECIFICATIONS |
|
Channels |
2 CH |
2 CH |
2 CH |
2 CH |
| Power Rating at 4Ω |
2 x 75 W |
2 x 100 W |
2 x 150 W |
2 x 200W |
|
Power Rating at 2Ω |
2 x 150W |
2 x 200 W |
2 x 300 W |
2 x 400w |
| Power Bridge at 4Ω |
1 x 300w |
1 x 400 |
1 x 600 W |
1 x 800 W |
|
Impedance |
4 Ω |
4 Ω |
4 Ω |
4 Ω |
| THD + N |
1% |
1% |
1% |
1% |
Signal to Noise Ratio
(@1 W into 4Ω ) |
-85dBA |
-90dBA |
-90dBA |
-78dBA |
| Crossover |
Fixed 100Hz |
20Hz~3KHz |
20Hz~3KHz |
20Hz~3KHz |
Dimension
(WxDxH) mm |
386 x 267 x 58 |
467 x 267 x 58 |
569 x 267 x 58 |
594 x 267 x 58 |
| |
|
|
|
|
| |
|
|
|
|
| |
|
|
|
|
| |
|
|
|
|
| |
|
|
|
|
| |
|
|
|
|
| |
|
|
|
|
| |
|
|
|
|
| |
|
|
|
|
|
| |
|
| |
|
|
