 SUBWOOFER |
|
|
 |
| |
|
FEATURE
-
600 Watts Peak /
200 Watts RMS
-
Cerwin-Vega's
Maximum Throw™ Suspension
-
High Temp 4 layer
Voice Coil
-
Rugged Die-cast
Aluminum Chassis
-
Powerful 14-lb
Motor Assembly
-
Designed for
Sealed or Ported Enclosure
|
| |
|
Model |
VMX 10 SVC |
SPECIFICATIONS |
|
Woofer Size |
10" |
|
No Voice Coil |
1 |
|
Sensitivity (2.8V @ 1M) |
90 dB |
|
Power Handling-Peak |
600 Watts |
|
Power Handling-RMS |
200 Watts |
|
Nominal Impedance |
4 Ω |
|
Voice Coil Dia. |
2" or 50.8mm |
|
Mounting Dia |
9 ¼" or 235 mm |
|
Mounting Depth |
5 5/8" or 142.9mm |
|
Spkr Displacement |
0.9 cu. ft. or 2.5 liters |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
