 SUBWOOFER |
|
|
 |
| |
|
FEATURE
-
Use Dual 2 Ω +
2Ω Voice Coil , Subs for 1 Ω or 4Ω Operation
-
Use Dual 4Ω +
4Ω Voice Coil, Subs for 2 Ω or 8 Ω
operation
-
Use Single 4 Ω
Voice Coil, Subs for multi-Woofer Sub Enclosures
-
High Energy
Magnet
-
For Ported or
Sealed Enclosure
-
Silver Laminate
Cone
-
Silver Speaker
Frame Color
-
Multi-Layer
High Temp VC
-
Front Plate &
Voice Coil Cooling
-
Integrated
Spider Tinsel Lead Design
-
High Excursion
Cone Surrounds
-
High Strength
Suspension Material
-
Push & Insert
Wire Terminals
-
Evolution of
Power Included
|
| |
|
MODEL |
SS 12 D 4 |
|
Specification |
|
Peak Power |
700 W |
|
RMS Power |
350 W |
|
VC Ω |
4+4 |
|
FS- HZ |
30.57 |
|
RE/Ω x2 |
3.6 |
|
Qts - |
0.956 |
|
Vas - liters |
42.11 |
|
Vas - Cu Ft |
1.49 |
|
Xmax-mm |
6 |
|
Xmax-inches |
0.59 |
|
SPL -dB @2,83V |
88.2 |
|
Sealed Enclosure Design |
|
Suggested Box Volume |
1 Cu Ft |
|
Box Poly Fill |
Loose |
|
|
|
|
Vented Enclosure Designs |
|
Suggested Box Volume |
2 Cu Ft |
|
Port I.D x Length |
4.0" x 11" |
|
Enclosure Resonance |
34 Hz |
|
Port Resonance |
36 Hz |
|
| |
