DVD Player
With TFT MONITOR /GPS/MAPKING |
|
|
|
| |
FEATURE
| • |
GPS CARD |
• |
MAPKING |
• |
Touch Screen |
| • |
MPEG 3
Digital Audio |
• |
Compact
Disc Audio |
• |
ESP Anti-Shock |
| • |
Video CD |
• |
Multimedia
Card |
• |
16:9 High
Definition |
| • |
DVD Video |
• |
USB |
• |
TV Tuner |
| • |
Bluetooth |
• |
MPEG 4 |
• |
SD |
|
Codec Details
|
|
AVI Container |
• |
DIVX |
• |
MPEG 4 |
| |
|
• |
ARCHOS |
• |
XVID |
|
MP4 Container |
• |
XVID |
• |
MOBILE |
|
Not support AVC
codec |
• |
IPOD video compatible |
|
|
|
| |
|
Feature
- 2 car dvd dvd car
audio with fixed faceplate
- 6.2-inch HD digital
color TFT touch screen, aspect ratio: 16:9, resolution:
800*480 pixels
- Graphical User
Interface
- DVD/MPEG4/DivX
5.0/Xvid/AVI/SVCD/VCD/CD/MP3/WMA/JPEG/CD-R/CD-RW/DVD-R/DVD-RW
Support
- Video and audio
output, and rear monitor video rearview mirror both
available
- Dual zone function:
drive can listen to music while viewing the map
- Built-in GPS navigation
function, voice guide, route plan, advanced POI Management
- Built-in Bluetooth,
support hand-free, dial-up and incoming call automatic
mute, A2DP, Phone book function
- SD/MMC card slot
with maximum 16G compatibility
- iPod®
Connectivity (Available for iPod NANO, Shuffle 3 etc)
- Multi-function
IR remote control operation
- Preset EQ function,
bass/treble/fader/balance controls
- Built-in AM/FM
Radio, RDS for optional
- Auto Store Pre-set
Scan
- Analog TV, PAL/NTSC/
SECAM (optional)
- With steering wheel
control function
- USB port and can
support direct control
- Parking Rear view
camera input
- Radio:
FM Frequency: 87.5-108MHz (Europe), Increment: 0.05MHz
AM Frequency: 522-1620KHz, Increment: 9 KHz
- In Radio mode,
can select Europe/USA/Japan/Russia radio frequency
- Tune method PLL
(Phase Locked Loop) frequency complex tune Storage quantity
FM radio: 18 channels, AM radio: 12 channels
- DVD Player:
Video output level: Compound1.0+0.2Vp-p (75Ω)
Compatible discs: DVD/MPEG4/DivX 5.0/AVI/VCD/CD/MP3/WMA/JPEG/CD-R/CD-RW/DVD-R/RW
- Disc spec: Diameter
12cm disc DVD OSD Language: English/German/Spanish/French/Portuguese
etc
|
| |
|
Model |
AV 936 GPS
|
|
SPECIFICATIONS
|
| Power
Supply Management |
10.8
~ 15VDC |
|
Speaker Load Impedance |
4 Ω |
| Max.
Power Output |
40
W x 4CH |
|
Tone Controls |
±8 dB (Bass 100 Hz,
Treble 10 KHz) |
|
|
|
|
Video Section
|
|
Video System |
NTSC / PAL/ AUTO /
SECAM |
| Aspect
Ratio |
16:9
/ 4:3 |
|
Video Output |
1.0Vp-p 75 Ω |
Horizontal Resolution
|
500
|
|
Audio Section |
|
Max. Output |
600 Ω (2.0Vrms) |
|
Frequency Scope |
20 Hz ~ 20 KHz |
|
S/N Ratio |
85 dB |
|
Resolution |
80 dB |
|
|
|
|
AM Tuning
|
|
Tuning Rage |
522 ~ 1620 (EUR/CN/RUS)
530 ~ 1710 USA |
|
MF Frequency |
450 KHz |
Practical Sensitivity(-20
dB)
|
25 dB
|
FM Tuner Section |
|
Frequency Scope MHz |
87.5 ~ 108 (EUR/CN)
65~74;87.5~108(RUS)
87.5 ~ 107.9 (USA) |
|
MF Frequency
|
10.7 MHz |
|
Effective Sensitivity
(-20 dB) |
15 dB |
|
S/N Ratio |
60 dB |
|
Stereo Channels Crosstalk |
30 dB(1 KHz) |
|
iPod®
is a registered trademark of Apple Computer, Inc.
This product is not designed, manufactured, sponsored,
licensed or distributed by Apple Computer, Inc |
|
| |
|
| |
|
|
