Amplifier |
|
|
 |
| |
|
FEATURE
-
2 ohm Stable
amplifier
-
MOS-FET Stable
Power Supply
-
Gold plated RCA
input Jack
-
Gold plated
Power and Speaker terminal
-
Thermal and
short protection
|
| |
|
Model |
SA - 5300 |
|
SPECIFICATIONS
|
|
Power output at 4Ω |
50 W x 4 + 300W |
|
Power output at 2Ω |
70 W x 4 + 480W |
|
Bridged power |
140 W x 2 + 300W |
|
Adjustable Input Sensitivity |
150 mV ~ 5 V |
|
Variable HPF/LPF frequency |
50 ~ 250 Hz |
|
Power Bass boost |
12 dB @ 45 KHz |
|
Frequency Response at +/- 1 dB |
10 ~ 30 KHz |
|
T.H.D |
0.05% |
|
Signal / Noise Ratio |
90 dB |
|
Separation |
60 dB |
|
Input Impedance |
10 K Ω |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
