 PRE-Amplifier |
|
|
5 Band Graphic
Equalizer |
| |
|
FEATURE
|
| |
|
Model |
PPI - EQP |
|
SPECIFICATIONS
|
|
Freq. Resp
|
1.5Hz-20kHz
|
|
S/N Ratio
|
110 dB
|
|
Supply Voltage
|
10V-15V
|
|
THD
|
0.03%
|
|
Maximum Output
|
6.7V RMS
|
|
Boost Cut Range
|
+/- 12dB
|
|
Sub Boost / Cut Range
|
+/- 18dB
|
|
Sub
|
40-120Hz
|
|
Low
|
250 Hz
|
|
Low-mid
|
500 Hz
|
|
High-mid
|
2 KHz
|
|
Treble
|
10 KHz
|
|
Subwoofer Crossover
|
50, 80 & 120Hz
|
|
Dimension
|
4.6" x 6.75" x 0.95" |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
| |
|
|
