 AMPLIFIER |
|
|
|
| |
|
TECH FEATURE:
- 2 Channel power
amplifier
- Symmetrical Topology
Regulated Triple-Split-Rail Power supply
- Zero-Noise isolated
input section utilizing Quasi-Differential
instrumental amplifier technology
- Up to 12 VRMS input
signal voltage capability (with 12dB attenuator)
- Fully independent
and Variable on board auxiliary crossover with assignable
RCA inputs and outputs.
Construction Feature:
- Mirror polished
stainless steel top plate
- Flycut billet aluminum
end plates
- Fully adjustable
mounting feet
- 3oz. gold plated
copper circuit board
- Massive 3-piece
proprietary heat sink
- Solid copper high
current power distribution busbars
- Top mount gain
and crossover control behind plexiglass security panel
|
| |
|
Model |
D7 152
|
SPECIFICATIONS |
|
RMS Output Power |
150 Watts x 2 @ 4
Ω Stereo |
| |
300 Watts x 2
@ 2 Ω Stereo |
| |
600 Watts x 1 Bridged
@ 4 Ω |
| Frequency Response |
3 Hz ~ 50 KHz |
|
Signal to Noise Ratio |
96 dB |
| THD
|
0.02% |
|
Channel Separation |
80 dB |
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
| |
|
| |
|
|
