 -Cassette
Player |
|
|
 |
| |
|
FEATURE
- AM/FM 2 BAND RADIO
- AUTO REVERSE CASSETTE PLAYER
- ROTARY TUNE UP/DOWN
- ROTARY VOLUME CONTROL
- LO/DX SELECTOR
- MUTE CONTROL
- 10 BAND EQUALIZER
- LCD DIGITAL DISPLAY
- RCA DIGITAL DISPLAY
- ANTI-THEFT PULLOUT CHASSIS
|
| |
|
Model |
KF 2610 |
SPECIFICATIONS |
|
Power Supply Requirements |
DC 12 Volts, Negative Ground |
|
Chassis Dimension |
181 [W] x 147 [D] x 53 [H] |
Maximum Output Power
|
2 CH x 7 W
|
FM Section |
|
Frequency Range |
88 MHz ~ 108 MHz |
|
Intermediate Frequency |
10.7 MHz |
|
Usable Sensitivity (Mon) |
Better than 25 dBu |
|
Stereo Separation at 1 KHz |
More than 24 dB |
|
|
|
AM Section |
|
Frequency Range |
530 KHz ~ 1700 KHz |
|
Intermediate Frequency |
455 KHz |
Usable Sensitivity (S/N 20 dB)
|
Better Than 42 dBu
|
Tape Section |
|
Tape Speed |
4.75 cm/sec (C-60tape) |
|
Wow & Flutter |
Less than 0.35% |
|
Cross Talk at 1 KHz |
More than 35 dB |
|
Channel Separation at 1 KHz |
More than 35 dB |
|
Frequency Response |
125 Hz ~ 8 KHz |
|
| |
